Technical data by comparison

Don't fill this field!

Show all	x TRH 20 E / TRH 21 E	x TRH 21 E	x TRH 22 E / TRH 23 E	x TRH 23 E	x TRH 24 E	x TRH 25 E / TRH 26 E	x TRH 26 E	x TRH 27 E	x TRH 28 E

Technical data Equipment, features and...	You save: 41 % 66.63 £ 39.13 £ plus VAT Show gross price (incl. VAT) You save: 41 % 79.95 £ 46.95 £ incl. VAT Show net price (VAT not included)	You save: 35 % 70.79 £ 45.79 £ plus VAT Show gross price (incl. VAT) You save: 35 % 84.95 £ 54.95 £ incl. VAT Show net price (VAT not included)	You save: 36 % 79.13 £ 49.96 £ plus VAT Show gross price (incl. VAT) You save: 36 % 94.95 £ 59.95 £ incl. VAT Show net price (VAT not included)	You save: 31 % 79.13 £ 54.13 £ plus VAT Show gross price (incl. VAT) You save: 31 % 94.95 £ 64.95 £ incl. VAT Show net price (VAT not included)	You save: 36 % 79.13 £ 49.96 £ plus VAT Show gross price (incl. VAT) You save: 36 % 94.95 £ 59.95 £ incl. VAT Show net price (VAT not included)	You save: 41 % 99.96 £ 58.29 £ plus VAT Show gross price (incl. VAT) You save: 50.00 £ 119.95 £ 69.95 £ incl. VAT Show net price (VAT not included)	You save: 33 % 99.96 £ 66.63 £ plus VAT Show gross price (incl. VAT) You save: 40.00 £ 119.95 £ 79.95 £ incl. VAT Show net price (VAT not included)	You save: 37 % 99.96 £ 62.46 £ plus VAT Show gross price (incl. VAT) You save: 45.00 £ 119.95 £ 74.95 £ incl. VAT Show net price (VAT not included)	You save: 37.50 £ 116.63 £ 79.13 £ plus VAT Show gross price (incl. VAT) You save: 45.00 £ 139.95 £ 94.95 £ incl. VAT Show net price (VAT not included)
Technical data
General information
Article number	1.410.000.710	1.410.000.711	1.410.000.715	1.410.000.716	1.410.000.717	1.410.000.720	1.410.000.721	1.410.000.722	1.410.000.723
Power
Level 1 [kW]	0.8	1	0.8	1	1	1	1	1.2	1.2
Level 2 [kW]	1.2	1.5	1.2	1.5	1.2	1.5	1.5	1.3	1.3
Level 3 [kW]	2	2.5	2.4	2.9	2.2	2.5	2.5	2.5	2.5
Level Max. [kW]	2	2.5	2.4	2.9	2.2	2.5	2.5	2.5	2.5
Effective range
Suitable for rooms sized up to [m²]	25	30	25	30	22	30	30	30	30
Suitable for rooms sized up to [m³]	60	75	60	75	55	75	75	75	75
Min. room temperature setting [°C]	10	10	10	10	10	15	15	10	16
Max. room temperature setting [°C]	35	35	35	35	30	35	35	30	30
Fans
Radial
Electrical values
Mains connection	220 - 240 V, 50/60 Hz	220 - 240 V, 50/60 Hz	220 - 240 V, 50/60 Hz	220 - 240 V, 50/60 Hz	220 - 240 V, 50 Hz	220 - 240 V, 50/60 Hz	220 - 240 V, 50/60 Hz	220 - 240 V, 50 Hz	220 - 240 V, 50 Hz
Max. power input [W]	2,000	2,500	2,400	2,900	2,200	2,500	2,500	2,500	2,500
Nominal current consumption [A]	8.7	10.9	10.4	12.6	9.5	10.9	10.9	10.9	10.9
Electric connection
Connection plug	CEE 7/7	CEE 7/7	CEE 7/7	CEE 7/7	CEE 7/7	CEE 7/7	CEE 7/7	CEE 7/7	CEE 7/7
Cable length [m]	1.4	1.4	1.4	1.4	1.8	1.4	1.4	1.8	1.8
Safety feature
IP type of protection	IP20	IP20	IP20	IP20	IP20	IP20	IP20	IP20	IP20
Protection class	I	I	I	I	I	I	I	I	I
Overheating protection
Dimensions
Length (wheeled) [mm]	390	480	420	490	442	470	470	465	446
Width (wheeled) [mm]	235	235	240	235	240	240	240	245	240
Height (wheeled) [mm]	558	548	650	635	639	600	600	645	635
Weight
(packaging excluded) [kg]	7	8	9	10	9	9.5	9.5	9.5	9.5
Equipment, features and functions
Mobility
Plastic wheels
Recessed handles
Functions and features
Number of heating fins	9	11	9	11	11	11	11	11	11
Auto restart function
Operating control lamp
Frost monitor function
Steplessly adjustable thermostat
Tilt protection switch
Turbo blower
Automatic temperature control
Thermostat-controlled automatic operation
Immediate heating due to direct infrared heat
Automatic switch-off upon reaching the set value
Cable winder
Plug holder
Housing design
Metal

standard equipment

optionally available

not available
