| Technical data |
| Article number |
3.510.205.081
|
3.510.205.085
|
| Measuring range |
0 lx up to 40,000 lx (0 fc up to 3,716 fc)
|
0 lx up to 40.000 lx (0 fc up to 3.716 fc)
|
| Accuracy | Light |
±5 % ±10 lx/fc (< 10,000 lx / 1,000 fc)
±10 % ±10 lx/fc (> 10,000 lx / 1,000 fc)
|
±4 % ±10 lx/fc (< 10.000 lx / 1.000 fc)
±10 % ±10 lx/fc (> 10.000 lx / 1.000 fc)
|
| Resolution | Light |
0.1 lx / 0.01 fc
|
0.1 (<200 LUX)
1 (<2000 LUX)
10 (<20000 LUX)
100 (<40000 LUX)
|
| Measurement rate |
2.5 x per second, nominal
|
1 x per second, nominal
|
| Extended data memory (microSD, optional) |
|
|
| Internal flash memory |
|
|
| Photo storage format |
|
|
| Video storage format |
|
|
| 3.5 headphone jack |
|
|
| USB |
|
|
| 4.0 (BLE) |
|
|
| Max. transmission range |
|
10 m in open terrain
|
| Monochrome |
|
|
| LCD |
|
|
| Colour |
|
|
| Touch |
|
|
| Plastics |
|
|
| Metal |
|
|
| Internal (battery) |
|
|
| External (power adapter) |
|
|
| External (USB) |
|
|
| Battery type |
9V battery
|
|
| 3 x 1.5 V, AAA |
|
|
| Operation - min. temperature [°C] |
0
|
-20
|
| Operation - max. temperature [°C] |
40
|
60
|
| Operation – max. relative humidity (non-condensing) [%] |
80
|
80
|
| Storage - min. temperature [°C] |
-10
|
-20
|
| Storage - max. temperature [°C] |
60
|
60
|
| Storage - max. relative humidity [%] |
|
90
|
| Length (packaging excluded) [mm] |
157
|
23
|
| Width (packaging excluded) [mm] |
34
|
38
|
| Height (packaging excluded) [mm] |
56
|
157
|
| (packaging excluded) [kg] |
0.138
|
0.111
|
| Standard scope of delivery |
| Measuring device |
|
|
| Bag/holster |
|
|
| Operating manual |
|
|
| Ascertainable measured values and functions |
| Light [lx] |
|
|
| Light [fc] |
|
|
| Maximum value display |
|
|
| Switching function lx/fc |
|
|
| Automatic switch-off |
|
|
| Sensor-controlled display illumination |
|
|
| ¼ inch tripod thread |
|
|
| LED connection indicator |
|
|
| Connection to Trotec MultiMeasure App |
|
|
| Battery warning |
|
|
| Can be remote-controlled via Trotec MultiMeasure |
|
|
| Minimum value display |
|
|
| Average value display |
|
|
| Measured value hold function |
|
|
| Alarm function |
|
|
